Roestvrij staal

SS 304L CR 240 Grid 1sf

Metals

RVS 304L KGW K240 1ZF is a cold-rolled, austenitic chromium-nickel stainless steel sheet with a ground surface (grain 240) and one-sided protective film. Thanks to its low carbon content (L = low carbon), this material is highly weldable without risk of intergranular corrosion. The combination of good corrosion resistance, attractive finish, and workability makes it ideal for visual applications in demanding environments.
Known alternative designations include 1.4307, AISI 304L, and X2CrNi18-9.

Laser cutting
Milling

Calculate price directly

RVS 304L KGW K240 1ZF cutting or milling

Properties of SS 304L CR 240 Grid 1sf

Ground surface (K240) with an aesthetic appearance
One-sided protective film (1ZF) prevents scratches during processing
Excellent corrosion resistance in various environments
Low carbon content prevents intergranular corrosion after welding
Good formability, suitable for bending and deep drawing
Flatness and thickness tolerances according to NEN-EN-ISO 9445-2
Not suitable for marine or highly chloride-rich environments
Dual certified as 1.4301 / 1.4307

These properties make RVS 304L KGW K240 1ZF a versatile choice for applications where both functionality and aesthetics are important.

Datasheet Title

Technical properties of SS 304L CR 240 Grid 1sf

Download datasheet

Product information and operations

Thickness	Dimensions	Color
1 mm	3000x1500 mm	Zilvergrijs (geslepen)
1.5 mm	3000x1500 mm	Zilvergrijs (geslepen)
2 mm	3000x1500 mm	Zilvergrijs (geslepen)
3 mm	3000x1500 mm	Zilvergrijs (geslepen)
4 mm	3000x1500 mm	Zilvergrijs (geslepen)
5 mm	3000x1500 mm	Zilvergrijs (geslepen)
6 mm	3000x1500 mm	Zilvergrijs (geslepen)
8 mm	3000x1500 mm	Zilvergrijs (geslepen)
10 mm	3000x1500 mm	Zilvergrijs (geslepen)
12 mm	3000x1500 mm	Zilvergrijs (geslepen)
15 mm	3000x1500 mm	Zilvergrijs (geslepen)

Technical properties

Algemeen

Dichtheid 7,9 g/cm³

Kleur Zilvergrijs (geslepen)

Oppervlakteafwerking Geslepen (K240) met eenzijdige folie

Temperatuurbereik

Gebruikstemperatuur minimaal -196 °C

Gebruikstemperatuur maximaal +550 °C

Mechanische eigenschappen

Treksterkte 500–700 MPa

Rek bij breuk ≥ 45%

Vloeigrens (Rp0,2) ≥ 190 MPa

Hardheid (Brinell) ca. 150 HB

Chemische samenstelling

Koolstof (C) ≤ 0,03%

Chroom (Cr) 17,5–19,5%

Nikkel (Ni) 8,0–10,5%

Mangaan (Mn) ≤ 2,0%

Silicium (Si) ≤ 1,0%

Fosfor (P) ≤ 0,045%

Zwavel (S) ≤ 0,015%

Thermische eigenschappen

Soortelijke warmte 500 J/kg·K

Lineaire uitzettingscoëfficiënt 16,5 × 10⁻⁶ /K

Warmtegeleidingscoëfficiënt 16 W/m·K

Applications of SS 304L CR 240 Grid 1sf

Food industry: countertops, storage tanks, and conveyor belts

Equipment manufacturing: housings and panels

Interior design: kitchen fronts and designer furniture

Medical devices: enclosures and work surfaces

Automotive: trim and interior parts

Machinery: visible components and protective covers

Retail & hospitality: counters and displays

Made with CutWise

Frequently Asked Questions about SS 304L CR 240 Grid 1sf

What does “KGW K240 1ZF” mean?

“KGW” stands for cold-rolled, “K240” refers to the 240-grit finish achieved by polishing, and “1ZF” indicates a protective film on one side.

Is 304L stainless steel suitable for food-industry use?

Yes, 304L meets all food-contact standards and is widely used in food processing.

Can 304L KGW K240 1ZF be welded?

Yes, its low carbon content ensures excellent weldability without risking intergranular corrosion.

What is the difference between 304 and 304L stainless steel?

304L has lower carbon content than 304, making it better for welding applications where intergranular corrosion must be avoided.

Is this material suitable for marine environments?

No, for chloride-rich or marine conditions, 316L is recommended due to its superior corrosion resistance.

What thicknesses are standard?

304L KGW K240 1ZF is typically available in 1 mm to 4 mm, depending on the supplier.

Can it be used for visible architectural work?

Yes, the smooth K240 surface and protective film make it perfect for decorative and exposed installations.

Is the material magnetic?

304L is austenitic and essentially non-magnetic, although slight magnetism can develop after heavy cold forming.
