Plastic
Hard PVC, also known as unplasticized PVC (PVC-U), is a rigid, dimensionally stable plastic with excellent chemical resistance and electrical insulation properties. The material is self-extinguishing, easy to machine, and has a long service life, making it widely used in technical and industrial applications.
Well-known brand names include Trovidur®, Simona® PVC-U, and Geon®.
Thanks to these properties, Hard PVC is a popular choice for a wide range of technical applications.
| Thickness | Dimensions | Color | Laser cutting | Milling | Bending | Glueable |
|---|---|---|---|---|---|---|
| 3 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 4 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 5 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 6 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 8 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 10 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 12 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 15 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 20 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 25 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 30 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 35 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
| 40 mm | 3000x1500 | Grijs RAL7011 | |
|
|
|
Dichtheid 1,38 g/cm³
Kleur Grijs, wit, zwart
Oppervlakteafwerking Glad, mat
Minimale gebruikstemperatuur -15°C
Maximale gebruikstemperatuur +80°C
Treksterkte 50–60 MPa
Elasticiteitsmodulus 3.000–3.500 MPa
Slagvastheid (Charpy) 2–5 kJ/m²
Diëlektrische sterkte ≥ 40 kV/mm
Oppervlakteweerstand 10¹³–10¹⁴ Ω
Warmtegeleidingscoëfficiënt 0,14–0,28 W/m·K
Lineaire uitzettingscoëfficiënt 80 × 10⁻⁶ /K
Chemical storage tanks and piping systems
Electrical cable trays and insulators
Machine and equipment construction
Air ducts and ventilation systems
Façade cladding and building profiles
Laboratory furniture and worktops
Water and sewer pipes
Signage and displays
Hard PVC (PVC-U) is unplasticized—stiff and dimensionally stable. Soft PVC contains plasticizers, making it flexible. Hard PVC is used for structural applications, while Soft PVC is suitable for hoses, cable jackets, and other flexible products.
Yes, Hard PVC resists weathering and UV, making it ideal for long-term exterior installations.
Yes, Hard PVC welds well with hot-air or solvent welding, enabling complex fabrication.
Yes, Hard PVC resists a wide range of chemicals, including acids, bases, and salts, making it perfect for chemical-processing equipment.
Hard PVC is self-extinguishing and flame-retardant, meeting various fire-safety standards.
Hard PVC sheets come in 1 mm to 50 mm thicknesses and various sheet sizes, depending on the supplier.
Yes, Hard PVC is fully recyclable and can be reused in new applications.
Hard PVC is easy to machine with standard tools: sawing, milling, drilling, and bonding are all straightforward.
Upload your DXF, STEP, AI, or EPS file and start your order immediately.
Select from plastic, rubber, steel, stainless steel, or aluminum for your part.
After the quote, choose the desired delivery time that fits your schedule.
Ordered? We start production at the right moment for your delivery.
Follow each step in real time, from production to delivery, for complete transparency.
